FNIRSI DSO-153 2-IN-1 Mini Digital Oscilloscope Waveform Generator

FNIRSI DSO-153 is a highly practical and cost-effective handheld oscilloscope designed for the maintenance industry and educational development. This oscilloscope has a real-time sampling rate of 5MS/s, a 1MHz bandwidth, and complete triggering functions (single, normal, auto). It can be used freely for periodic analog and non-periodic digital signals. It can measure up to ±400V with an efficient one-click AUTO feature, displaying the measured waveform without complicated adjustments. Additionally, it features a function signal generator capable of outputting 14 types of signals (10KHz). Equipped with a 2.8-inch 320*240 resolution HD LCD screen and a built-in 1000mAh high-quality lithium battery, it can be used for about 4 hours when fully charged.

Basic Specifications:

Sampling Rate (Oscilloscope): 5MSa/s
Bandwidth (Oscilloscope): 1MHz
Vertical Sensitivity (Oscilloscope): 10mV/Div – 20V/Div
Time Base Range (Oscilloscope): 500ns/Div – 20s/Div
Voltage Range (Oscilloscope): X1: ±40V (Vpp: 80V), X10: ±400V (Vpp: 800V)
Trigger Method (Oscilloscope): Auto / Normal / Single
Coupling Method (Oscilloscope): AC/DC
Frequency Range (Signal Generator): 0-10KHz
Duty Cycle Range (Signal Generator): 0-100%
Amplitude Range (Signal Generator): 0.1-3.3V
Display: 2.8 inches, Resolution: 320 x 240
USB Charging: 5V/1A
Lithium Battery Capacity: 1000mAh

Functionality and Features:

Oscilloscope:

– Progressively adjustable vertical sensitivity and time base range for detailed signal analysis.
– Versatile trigger methods including Auto, Normal, and Single for precise waveform capture.
– AC/DC coupling methods for flexible signal measurements.

Signal Generator:

– Generates various waveforms including sine waves, rectangular waves, sawtooth waves, and more for signal testing and analysis.
– Adjustable frequency, duty cycle, and amplitude for waveform customization.

Package Contents:

Standard Package:

Host device * 1
Alligator clip probe * 1
Charging cable * 1
Lanyard * 1
User Manual * 1
Packaging color box * 1

Option Package (with P6100 High Voltage Probe):

Host device * 1
P6100 High Voltage Probe * 1
Adapter * 1
Alligator clip probe * 1
Charging cable * 1
Lanyard * 1
User Manual * 1
Packaging color box * 1
